UV Roller Varnish For Paper
Price:
UV Roller Varnish For Paper
Product Description
UVG-250 uv roller varnish is suitable for the whole-sheet roll coating of paper (applicable substrate: copper paper and white card paper, etc.). With good adhesion, flexibility, wear resistance and other characteristics, to provide good luster, wear resistance and other properties. This product is a base-free light oil, which can simplify the process and save the production cost.
Safety standards Of UV Roller varnish:
(1)UVG-250 uv roller varnish Meet the EU EN71 PART 3 standards for heavy metal content.
(2)UVG-250 uv roller varnish Comply with the limit requirements of the Revised Directive (EU) 2015 / 863 as in Appendix II of the EU RoHS Directive 2011 / 65 / EU.
(3) Pass the phthalate (or ester) safety standards.
(4) Comply with EU Regulation No.1907 / 2006.
For more details please contact Foshan Raywin-BGP
Ink technical parametersOf UV Roller varnish:
Recommended Instructions of UV Roller varnish:
1. Stir or shake well before use to prevent stratification of light oil during placement.
2. The viscosity of UVG-250 uv roller varnish has been adjusted to the use viscosity. Generally, special diluent is not required.
3. When used, the coating thickness is recommended to be 10~12um, and the coating amount of 10g / ㎡ UV photofixation energy is set to 50~80mj / cm2The transfer speed is set to about 40M / min to ensure sufficient curing, otherwise the surface return adhesion and paint loss during the placement process will occur.
4. It is recommended to choose more than 2 medium and high pump lamps, line power 100W / ㎝, single lamp power 5k w / branch, lamp pipe is 12~15 ㎝ away from the substrate, lamp service life of 800 hours, replaced in time after aging, to ensure full curing.
More details please visit: www.raywincoating.com
Product Description
UVG-250 uv roller varnish is suitable for the whole-sheet roll coating of paper (applicable substrate: copper paper and white card paper, etc.). With good adhesion, flexibility, wear resistance and other characteristics, to provide good luster, wear resistance and other properties. This product is a base-free light oil, which can simplify the process and save the production cost.
Safety standards Of UV Roller varnish:
(1)UVG-250 uv roller varnish Meet the EU EN71 PART 3 standards for heavy metal content.
(2)UVG-250 uv roller varnish Comply with the limit requirements of the Revised Directive (EU) 2015 / 863 as in Appendix II of the EU RoHS Directive 2011 / 65 / EU.
(3) Pass the phthalate (or ester) safety standards.
(4) Comply with EU Regulation No.1907 / 2006.
For more details please contact Foshan Raywin-BGP
Ink technical parametersOf UV Roller varnish:
project | surface | Viscosity (25℃. Coat 4 cups) | adhesion | Insulation | levelling property |
metric | transparency liquid | 26 ± 2 seconds | good | good | good |
project | alcohol resistance | Gloss / 60° gloss | Light solid energy | Curing speed | UV absorption peak |
metric | Level 4 | 85 ± 3 degrees | 50~80mj/cm2 | ≥40M /min | 365nm |
Recommended Instructions of UV Roller varnish:
1. Stir or shake well before use to prevent stratification of light oil during placement.
2. The viscosity of UVG-250 uv roller varnish has been adjusted to the use viscosity. Generally, special diluent is not required.
3. When used, the coating thickness is recommended to be 10~12um, and the coating amount of 10g / ㎡ UV photofixation energy is set to 50~80mj / cm2The transfer speed is set to about 40M / min to ensure sufficient curing, otherwise the surface return adhesion and paint loss during the placement process will occur.
4. It is recommended to choose more than 2 medium and high pump lamps, line power 100W / ㎝, single lamp power 5k w / branch, lamp pipe is 12~15 ㎝ away from the substrate, lamp service life of 800 hours, replaced in time after aging, to ensure full curing.
More details please visit: www.raywincoating.com
