salt fog test chamber(Salt /Temperature /Humidity)

Introduction

Cyclic Corrosion Test Chamber can perform multiple tests, including: Salt Fog, Heating and Cooling, Humidity, Drying.The tests are programmable. You can set the test procedures according to your requirements.
In addition to the function of the usual salt spray tester, it also combines the function of alternating (circulating) salt spray test to provide a test environment such as caricature corrosion and filamentous corrosion. It has hot air drying, damp heat, forced drying and salt spray and other test environment.
The main test items are for the use of items in the environment with severe changes, such as: automotive parts, aviation equipment, building materials, coating electric, electrical machines, etc., combined with salt spray, dry, wet heat and cycle testing.If you need more models about our test equipment, please reference our chamber-testing（.）com
Meet standard:
DO160 E/F/G  Salt spray test requirements
GB/T 20854-2007/ISO14993-2001
    Accelerated testing of corrosion cycles of metals and alloys exposed to salt spray, "dry" and "wet" conditions
GB/T24195-2009/ISO 16151:2005 Cyclic accelerated corrosion tests under acid salt spray, dry and wet conditions
GJB 150.11A-2009  Military equipment laboratory environmental test method salt spray test
GB/T 2424.17-2008/IEC60068-2-11:1981  Salt spray test method
GB/T 2423.18-2012/IEC 60068-2-52: 1996  Alternating salt spray test method for sodium chloride
GB/T 2423.3-2006/IEC6008-2-78-2001 Test cab: constant wet heat test method
GB/T 10125-2012/ISO9227-2006 Corrosion test in artificial atmosphere salt spray test
GB/T 31467.3-2015
    Lithium-ion power battery packs and systems for electric vehicles
- Part 3: Safety requirements and test methods: Salt spray test
ASTM B117,ASTM B368
GB/T 10587-2006  Salt spray test chamber technical conditions
GB/T 10586-2006  Wet heat test chamber technical conditions
GB/T 5170.8-2008_Test method for environmental test equipment for electrical and electronic products-salt spray test equipment
1.Structure of Salt Mist Test Chamber: with enclosure is a fully anti-corrosion structure, made of multi-layer fiberglass reinforced polyester resin, and constructed with corrosion-resistant materials.
2.Unique design: Large spraying area and high flow rate, resulting in shorter spraying time compared to fogging the solution under salt spray function.
3.Custom nozzle: Specific nozzles evenly spray the solution onto the test sample, and the solution flow rate can be adjusted.
4.The nozzle is installed on an independent module, making it easy to remove when fogging function is enabled.
5.Programmable touch screen controller allows for operation in both Chinese and English, and enables data collection.
6.Standard test specimen racks are provided, capable of accommodating flat samples. For oversized and heavy three-dimensional samples (such as automobile hubs and engine components), grid kits with the same height as the support can be used. The enclosure is structurally robust, allowing for even distribution of the load.

7.The spray on/off time can be programmed directly to better control the corrosion rate.
