WIZ Hydraulic Cargo Lift with Safety Enclosure

Price:

Hydraulic cargo lift

The cargo lift are the most cost-effective arrangement, enabling users to move car or goods safely and efficiently between two or more floors. It provides fast, efficient,convenient and safe access to mezzanines, balconies, basements, and any levels in multistoried building. It can be installed indoor and outdoor applications. Also, the cargo lift is widely used in factories, warehouses, industrial plants, institutions

[START]

Main model

[/START]

Model	Load capacity	Lifting height	Platform size	power	Loading direction
CL0.5-2.8	500kg	2800mm	1200x1200mm	2.2kw	1200mm
CL1-5.5	1000kg	5000mm	1600x2500mm	3.0kw	2500mm
CL3-3	3000kg	3000mm	2500x5000mm	4.0kw	2500mm
CL5-10	5000kg	10000mm	7500x2000mm	5.5kw	2000mm
CL10-15	10000kg	15000mm	3300x6000mm	7.5kw	6500kg
Note: Load capacity, lifting height, platform size, voltage all can be made as customer requirement.

[START]
[/START]

Features< style="box-sizing: border-box; margin: 0px; padding: 0px; list-style: none;">
[START]
[/START]

[START]

1. Floor mounted, no pit required and head room
2. Does not require conventional lift well / room
3. Can come down in case of power cut by opening manual valve
4. Can be totally customized for your needs / space available
5. Very economical compared to conventional lifts
6. Anti-slip platform surface
7. Both level gates fitted with electrical and mechanical interlocks
8. Emergency stop button

[/START]Safety configuration

Hydraulic elevators not only have all safety device of the traditional elevator, but also have the special system:< style="box-sizing: border-box; margin: 0px; padding: 0px; list-style: none;">

■ Spillover valve, it can prevent high pressure when the machine moves up.< style="box-sizing: border-box; margin: 0px; padding: 0px; list-style: none;">

■ Manual emergency valve, it can go down to the nearest floor and open the door when meet an emergency.< style="box-sizing: border-box; margin: 0px; padding: 0px; list-style: none;">

■ Manual pump, it can go down to the nearest floor and open the door when meet an emergency.< style="box-sizing: border-box; margin: 0px; padding: 0px; list-style: none;">

■ Pipe fracture valve, when the hydraulic system pipe fracture, it can cut down the channel of the oil to stop the falling.

Customized your cargo lift solutions

There are three basic details that will help you get a cargo lift solutions< style="box-sizing: border-box; margin: 0px; padding: 0px; list-style: none;">

[START]

The lifting height
The top platform size
The load capacity

[/START][START]< data-filtered="filtered" style="box-sizing: border-box; margin: 0px; padding: 0px; list-style: none;">[/START]

Once we get the above three important parameters, WIZ lift will provide you a best suitable lifting solutions.
